deluxe control smokers • installation/operation/service manual - pg. 10
The appliance must be installed by a qualified
service technician. The oven must be properly
grounded in accordance with the National Electrical
Code and applicable local codes.
Plug the unit into a properly grounded receptacle
ONLY, positioning the unit so that the plug is easily
accessible in case of an emergency. Arcing will occur
when connecting or disconnecting the unit unless all
controls are in the “off” position.
Proper receptacle or outlet configuration or
permanent wiring for this unit must be installed by
a licensed electrician in accordance with applicable
local electrical codes.
Supply cords used with this equipment shall be
oil-resistant, sheathed flexible cable not lighter
than ordinary polychloroprene or other equivalent
synthetic elastomer-sheathed cord (Code designation
60245 IEC).
REGARDING INTERNATIONAL STANDARD UNITS:
If the unit is not equipped with flexible cord and
plug, an all-pole country approved disconnection
device which has a contact separation of at least 3mm
in all poles must be incorporated in the fixed wiring
for disconnection. When using a cord without a plug,
the green/yellow conductor shall be connected to the
terminal which is marked with the ground symbol.
If a plug is used, the socket outlet must be easily
accessible. If the power cord needs replacement, use
a similar one obtained from the distributor.
ELECTRICAL CONNECTION
INSTALLATION
DANGER
ENSURE POWER SOURCE
MATCHES VOLTAGE STAMPED
ON APPLIANCE NAMEPLATE.
DANGER
To avoid electrical shock, this
appliance MUST be adequately
grounded in accordance with local
electrical codes or, in the absence of
local codes, with the current edition
of the National Electrical Code ANSI/
NFPA No. 70. In Canada, all electrical
connections are to be made in
accordance with CSA C22.1, Canadian
Electrical Code Part 1 or local codes.
Wire diagrams are located inside the bonnet of the unit.
ELECTRICAL - 767-SK/III
vOLTaGE PHaSE cycLE/Hz aMPS kW aWG
208-240 (agcy) 1 60 16.0 3.9
cord,
at 208 1 60 15.5 3.2
no plug
at 240 1 60 17.9 4.3
230 1 50/60 15.4 3.1 cee 7/7
220-230v plug
ELECTRICAL - 1767-SK/III
vOLTaGE PHaSE cycLE/Hz aMPS kW aWG
208-240 (agcy) 1 60 32.0 7.7 no cord
at 208 1 60 31.0 6.5 or plug
at 240 1 60 35.8 8.6
230 1 50 29.1 6.1 no cord
or plug
ELECTRICAL - 1000-SK/III
vOLTaGE PHaSE cycLE/Hz aMPS kW cOrD & PLuG
208-240 (agcy) 1 60 15.8 3.8
no cord
at 208 1 60 14.4 3.0
or plug
at 240 1 60 16.7 4.0
230 1 50 14.0 2.8 cee 7/7
220-230v plug
ELECTRICAL - 1200-SK/III
vOLTaGE PHaSE cycLE/Hz aMPS kW cOrD & PLuG
208-240 (agcy) 1 60 33.3 8.0
no cord
at 208 1 60 30.6 6.4
or plug
at 240 1 60 35.4 8.5
230 1 50 31.5 7.2 no cord
or plug
NOTE: CE approved appliances must be
connected to an electrical circuit that is
protected by an external GFCI outlet.
Hard wired models:
Hard wired models must be equipped with a
country certified external allpole disconnection
switch with sufficient contact separation.
If a power cord is used for the connection of the
product an oil resistant cord like H05RN or H07RN
or equivalent must be used.
DANGER
ELECTRICAL CONNECTIONS MUST
BE MADE BY A QUALIFIED SERVICE
TECHNICIAN IN ACCORDANCE WITH
APPLICABLE ELECTRICAL CODES.
For CE approved units: To prevent an electrical
shock hazard between the appliance and other
appliances or metal parts in close vicinity, an
equalization-bonding stud is provided. An
equalization bonding lead must be connected to
this stud and the other appliances / metal parts
to provide sufficient protection against potential
difference. The terminal is marked
with the following symbol.
