deluxe control smokers • installation/operation/service manual - pg. 25
SERVICE
EXTERIOR SERVICE PARTS LIST
A
*not shown
MODEL > 767-SK/III 1000-SK/III
ITEM DESCRIPTION PART NO. QTY PART NO. QTY
1 GUARD SENSOR 1493 1 1493 1
2 CHIP TRAY 4652R 1 4652R 1
2a CHIP TRAY INSERT 1243 1 1243 1
3* PROBE HOLDER 13239 1 13239 1
4 SHIM, LATCH 13947 1 13947 1
5 DRIP PAN 14831 1 5005616 1
6 CASTER SPACER 1007145 12 1007145 12
7 BACK CASING 1010393 1 1011878 1
8 BOTTOM PANEL 1010394 1 1009941 1
9 SIDE PANEL 1010395 2 1010575 2
10 BONNET, TOP COVER 1010401 1 1009951 1
11 ELEMENT COVER 1010409 1 1011813 1
12* SMOKE HEATER PLATE WELD 5003782 1 5003782 1
13 PROBE COVER WELDMENT 5009712 1 5009712 1
14
INSULATION IN-22364
1
IN-22364
1
15 DRIP TRAY KIT 5010391 1 5009716 1
DRIP TRAY 1010584 1 1010188 1
DRIP TRAY HOLDER 1010585 1 1010189 1
SCREWS SC-2459 3 SC-2459 3
16
DOOR ASSEMBLY, RH
5011828 1
5012859
1
DOOR ASSEMBLY, LH 5011829 1 5012861 1
17 BONNET ASSBY, SPOT
5010047
1
5009280
1
18
BLOCK, MTG, SENSOR
BK-24427 1 BK-24427 1
19*
BLOCK, 2 TERMINAL, PORCELAIN BK-33546 3 BK-33546 3
20* BRACKET, CHIP TRAY BT-29217 1 BT-29217 2
21
3/8" HOLE BUSHING, BLACK
BU-3419 1 BU-3419 1
22*
5/8" SNAP BUSHING, BLACK
BU-3611 1 BU-3611 1
23* CABLE, SMOKE HEATER
EL-35022
1
EL-35022
1
24
CASTER, 3-1/2" RIGID
CS-25674 2 CS-25674 2
25
CASTER, 3-1/2" SWIVEL W/ BRAKE
CS-25675 2 CS-25675 2
26 COVER, HINGE CV-22171 2 CV-22171 2
27* GASKET ASSEMBLY, DOOR GS-22951 1 GS-22952 1
28
GASKETS, ADHESIVE, .125 X .375 [lin ft]
GS-23622 1 GS-23622 1
29 HANDLE, OFFSET MAG LATCH HD-27080 1 HD-27080 1
30 HINGE, 1-3/8 OFFSET, CHROME HG-22338 1 HG-22338 1
31 INSULATION IN-2003 1 IN-2003 1
32 RATING TAG LABEL LA-26348 1 LA-26348 1
33* NUT, 1/4-20 HEX S/S NU-2437 4 NU-2437 4
34* PANEL OVERLAY MENU CARD PE-23384 1 PE-23384 1
35 PROBE ASSEMBLY PR-34298 1 PR-34298 1
36 PROBE, RECEPTICAL PR-34705 1 PR-34705 1
37 10-32 X 3/4 PHILLIPS PAN HD SC-2071 2 SC-2071 2
38
SCREW, 10-32 X 3/4, NF, PHIL,FLAT M/S, #18-8 S/S
SC-2072 6 SC-2072 6
39
SCREW, 10-32 X 1-1/2, NF, PHIL,FLAT M/S, #18-8 S/S
SC-2073 10 SC-2073 10
40
SCREW, 6-32 X 1/2, NC PHIL,FLAT
SC-2239 2 SC-2239 2
41*
SCREW, 1/4-20 X 1/2, NC SLOT RND
SC-2332 4 SC-2332 4
42
8-32 x 1/4" PHIL SCREW
SC-2459 36 SC-2459 36
43 S/S WIRE SHELF SH-2324 2 SH-2325 2
44* S/S WIRE SHELF, RIB RACK SH-2743 1
SH-29474
1
45
SENSOR, 1-3/4" L
SN-33541 1 SN-33541 1
46 SIDE RACK, STAINLESS STEEL SR-28405 2 SR-2266 2
47 DOOR SWITCH, REED, SPST SW-33559 1 SW-33559 1
48 CORD, 230V/50HZ ONLY CD-3922 1 CD-3922 1
