TH-II INSTALLATION/OPERATION/SERVICE MANUAL PG. 23
S E R V I C E
C AB L E HE AT IN G
S ER V IC E KI T S
i
ncludes:
CB-3045 Cable Heating Element . . . . 210 feet
CR-3226 Ring Connector. . . . . . . . . . . . . . . 12
IN-3488 Insulation Corner . . . . . . . . . . 1 foot
BU-3105 Shoulder Bushing . . . . . . . . . . . . . 12
BU-3106 Cup Bushing. . . . . . . . . . . . . . . . . 12
ST-2439 Stud. . . . . . . . . . . . . . . . . . . . . . . . 12
NU-2215 Hex Nut . . . . . . . . . . . . . . . . . . . . 24
SL-3063 Insulating Sleeve . . . . . . . . . . . . . 12
TA-3540 Electrical Tape. . . . . . . . . . . . . 1 roll
No. 4881
MODELS 750-, 1000-TH-II
i
ncludes:
CB-3045 Cable Heating Element . . . . 134 feet
CR-3226 Ring Connector. . . . . . . . . . . . . . . . 4
I
N-3488 Insulation Corner . . . . . . . . . . 1 foot
B
U-3105 Shoulder Bushing. . . . . . . . . . . . . . 4
BU-3106 Cup Bushing. . . . . . . . . . . . . . . . . . 4
ST-2439 Stud . . . . . . . . . . . . . . . . . . . . . . . . 4
N
U-2215 Hex Nut . . . . . . . . . . . . . . . . . . . . . 8
SL-3063 Insulating Sleeve . . . . . . . . . . . . . . 4
T
A-3540 Electrical Tape. . . . . . . . . . . . . 1 roll
No. 4880
MODEL 500-TH-II
P
ART DESCRIPTION
Q
TY.
P
ART NUMBER
Contactor
120V
208-240V, 230V
1
1
CN-3487
CN-3052
Cordset
120V
2
08-240V
230V
6 ft
–
–
9 ft
CD-3922
–
–
CD-3397
Fan, Box
120V
208-240V, 230V
1
1
FA-3973
FA-3974
Ground Screw 1 SC-2190
Heat Sink 1 1005836
Indicator Light
120V
208-240V, 230V
2
2
LI-3027
LI-3951
Line Filter (230V only) 1 FI-33225
Switch, Power 1 SW-34375
Switch, Voltage (208-240V AND 230V ONLY) 1 SW-3528
Terminal Block, Power 1 BK-3019
Terminal Block 2 BK-3023
Thermostat, Cook 1 TT-3329
Thermostat, Hold 1 TT-3057
Thermostat, Hi-Limit (NOT SHOWN) 1 TT-33476
Timer, 12 hour
120V
208-240V
230V
1
1
1
TR-3504
TR-3318
TR-3402
E L E C T R O N I C CO M P O N E N T S PA R T S L I S T
D A N G E R
DISCONNECT UNIT FROM
POWER SOURCE BEFORE
CLEANING OR SERVICING.
D A N G E R
L OC K -O U T OR PO ST
BR E A KE R PAN EL U NT I L
S ER VI C E WO RK H AS
BE E N CO MP L E TE D .
