Cuisinart DGB-600BC Coffeemaker User Manual



6
13. Grinder Basket Lid
Use the recess on each side of the
lid to remove lid for easy addition of
beans. Note: Lid must be in place
for unit to operate.
14. Grinder Basket
15. Charcoal Water Filter
(not shown)
Charcoal water filter eliminates
chlorine, bad tastes and odors
from tap water.
16. Water Reservoir with Water
Level Indicator
17. Filter Basket Cover
To put on, match “FRONT” arrow
with front of brew basket door. To
remove, lift cover in area indicated
by “LIFT” arrow. NOTE: COVER
MUST BE IN PLACE FOR UNIT TO
OPERATE CORRECTLY. Cover
becomes hot after coffee
is brewed. Use caution when
removing cover.
18. Gold Tone Cuisinart
Commercial Style Filter
(not shown)
A note about filters: When using
our permanent filter, be sure that
the handle is positioned toward the
front of the unit. If you do not, the
handle may interfere with the flow
of coffee into the filter basket.
Also note: using our permanent
gold-tone filter will allow some
fine coffee grounds to fall into the
coffee carafe. This will appear as
sediment in the carafe.
19. Filter Basket
Holds our commercial style
permanent filter or paper filter.
NOTE: FILTER BASKET HOLDER
MUST BE IN PLACE FOR UNIT
TO OPERATE CORRECTLY.
Removable for easy cleaning.
13
14
17
19
16
