9
Determinethe11. required framework height.Todeter-
minetherequiredframeworkheight:
Putthetopframeworkpieceoverthebottomframework12.
piece.Themountingslotsonthetoppiecemustbeup.
Usefourmachinescrewstofastenthetoppieceto13.
thebottompiece.Thetotalheightofthetwopieces
togethermustequaltherequiredframeworkheight
determinedabove.
Removetheprotectiveplasticcoveringfromboth14.
piecesofthechimneyassembly.Donotremovethe
protectivetapestripsfromtheinside.Theyprotectthe
telescopingpiecesfromscratchingduringinstallation.
Carefullyslidebothsectionstogethersothatonlythe15.
ventsonthetopsectionshow.
Holdthechimneyverticallywiththeventsup.16.
Carefullyputthechimneyoverthetopofthe17.
framework,takingcarenottoscratchthesurfaces.
MakesuretheDacorlogofacesthesamesideasthe
controlpanel.
Makesureanywiresaretuckedinbehindthechimney18.
andarenotpinched.
in s T a l l a T i o n in s T r u C T i o n s
Measurethedistancefromtheceilingtothe•
cooktop.
Subtracttheheightatwhichthehoodwillbe•
mounted(30”minimum)andthehoodthickness
(121/2”)fromthedistancemeasured.
CHIMNEY
HOOD
TOP
FRAMEWORK
BOTTOM
FRAMEWORK
MOUNTING
SLOTS
