Maintenance
WARNING
Disconnect electric power to the ice maker
before cleaning the condenser.
To remove and replace the grille for access to the
condenser fins follow this procedure (see Figure
29):
1 Remove the screws at each end of the grille.
2 Remove the grille.
Condenser Cleaning — Every
3 Months
To maintain operational efficiency, clean the
condenser every three months (depending on
environmental conditions, more or less frequent
cleaning may be necessary).
WARNING
DO NOT touch the condenser fins. The
condenser fins are SHARP. The fins can also
be easily damaged.
CAUTION
DO NOT use any type of cleaner on the
condenser unit.
3 Clean the condenser coil using a brush with
a “combing” action, or a vacuum cleaner. Do
not touch the condenser coil.
4 Clean the grille, then position the grille to
align the screw holes with the cabinet.
5 Insert the grille screws and tighten. Do not
over tighten.
Self Cleaning — Every 6 Months
To maintain operational efficiency, clean the unit
every six months (depending on water conditions
more or less frequent cleaning may be necessary).
If the ice maker requires more frequent cleaning,
consult a qualified plumber to test the water quality
and recommend appropriate treatment.
WARNING
Wear rubber gloves and safety goggles and/
or face shield when handling Ice Machine
Cleaner.
CAUTION
Use only Electrolux Ice Machine Cleaner (part
number EIM30046).
It is a violation of Federal law to use this
solution in a manner inconsistent with its
labeling. Use of any other cleaner can ruin
the finish of the evaporator and will void the
warranty.
Read and understand all labels printed on the
package before use.
Ice machine cleaner is used to remove lime scale
and other mineral deposits. Refer to the following
steps for mineral deposit removal.
CAUTION
Never use anything to force ice from the
evaporator. Damage may result.
1 Turn the ice maker off (allowing any ice to
melt off of the evaporator) as follows:
a Touch and hold the POWER button.
b The display will switch from ICE to OFF
to confirm that the ice maker is off. (See
Figure 30.)
Figure 29
OFF
POWER
DOWN
ARROW
LIGHT,
BLACKOUT MODE
& OTHERFUNCTIONS
DISPLAY
UP
ARROW
Figure 30
