8
Remove the two screws from each cover over the
top door hinges.
2 Lift hinge cover straight up and off.
Detach the multi-wire cable connector located
above the top hinge. Grasp both sides of the
connectorrmlyandpullapart.
3 Detach the water tube from the connector
located below the freezer door. The connector
releases when you press its outer sleeve inward.
4 Remove the screws from the top hinge and
pull the multi-wire cable through it. Lift the
door off of the bottom hinge.
Remove the two bottom hinge screws and
hinge if necessary.
Lay the door on its side to avoid damage to
the water tube extending from the bottom
hinge.
To reinstall the freezer door, reverse the above steps.
Once both doors are in place, ensure they are aligned
with each other and level (Please see “To level the doors
using the lower hinge” for models with adjustable lower
hinges or “To level the cabinet using the front rollers”
for models with the non-adjustable lower hinges in the
“Installation” section.), then replace the top hinge cover.
2 Trace lightly around the hinge with a pencil.
This makes reinstallation easier.
