Part # 4521635 (03/04/08)Page 4
SECTION 2 – TECHNICAL INFORMATION
Model BH/BA (Counter models) 120 V/1 Ph 208 V/1 Ph 240 V/1 Ph
Wattage kW 1.5/1.8 kW 2.5/3.5 kW 2.5/3.5 kW
Current A 12.5/15 12/14.5/17 10/12.5/14.5
Power factor Cos ϕ >0.95 >0.95 >0.95
Discharge rate mA 4 4 4
∅ Coil mm 190 (7.5”) 190 (7.5”) 190 (7.5”)
Model BH/IN (Counter Models) 208 V/1 Ph 240 V/1 Ph
Wattage kW 2.5 kW 2.5 kW
Current A 12 10
Power factor Cos ϕ >0.95 >0.95
Discharge rate mA 4 4
∅ Coil mm 190 (7.5”) 190 (7.5”)
Model SH/BA (Counter Models) 208 V/1 Ph 240 V/1 Ph 208 V/3 Ph
Wattage kW 3.5 kW 3.5 kW 5 kW
Current A max. 16 14.5 max. 16
Power factor Cos ϕ >0.95 >0.95 >0.95
Discharge rate mA 4 4 4
∅ Coil mm 190 (7.5”) 190 (7.5”) 190 (7.5”)
Model SH/IN (Built in Models) 208 V/1 Ph 240 V/1 Ph 208 V/3 Ph
Wattage kW 3.5 kW 3.5 kW 5 kW
Current A max. 16 14.5 max. 16
Power factor Cos ϕ >0.95 >0.95 >0.95
Discharge rate mA 4 4 4
∅ Coil mm 190 (7.5”) 190 (7.5”) 190 (7.5”)
Model SH/WO (Counter Wok Models) 208 V/1 Ph 240 V/1 Ph 208 V/3 Ph
Wattage kW 3.5 kW 3.5 kW 5 kW
Current A max. 16 14.5 max. 16
Power factor Cos ϕ >0.95 >0.95 >0.95
Discharge rate mA 4 4 4
∅ Coil mm 190 (7.5”) 190 (7.5”) 190 (7.5”)
Model SH/WO/IN (Built in Wok Models) 208 V/1 Ph 240 V/1 Ph 208 V/3 Ph
Wattage kW 3.5 kW 3.5 kW 5 kW
Current A max. 16 14.5 max. 16
Power factor Cos ϕ >0.95 >0.95 >0.95
Discharge rate mA 4 4 4
∅ Coil mm 190 (7.5”) 190 (7.5”) 190 (7.5”)
