Refrigerator Location
Clearances
Do not install refrigerator where temperature will
Allow the following clearances for ease of
go below
60°F.
because it will not run often enough
instillation, proper air circulation and plumbing
to maintain proper temperatures.
and electrical connections:
Do install it on a floor strong enough to support it
Sides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..5/8”
fullv loaded.
TOP
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .......0”
“
Also see Energy-Saving Tips.
(~%uilt in, allow 7/8’’ for hinge covers.)
Back. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1“
Allow following door clearances:
Refreshment Center Side ..............374’
Freezer Side
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1%”
Rollers~eveling
Legs
Adjustable roller behind the base grille enable you to
move the refrigerator away from the wall for cleaning.
These rollers should be set so the refrigerator rests
firmly on the floor. To assure that the doors will close
automatically from a halfway-open position, there is a
built-in tilt from the front to the back of the cabinet.
Side-by-side refrigerators
dso
have specially designed
door hinges that lift both doors slightly when opened,
allowing the force of gravity to help close them securely.
To adjust rollers,
remove the base grille by
grasping it at the bottom
and pulling it out.
~rn
roller adjusting screws
clockwise to raise refrigerator,
counterclockwise to lower it.
Use adjustable wrench (3/8” hex
head bolt) or pliers.
E
&
When adjusting front rollers for
proper door closure, we recommend that the bottom
front edge of the cabinet be approximately 5/8” from
the floor.
To replace base grille,
align prongs on back
of grille with clamps in
cabinet and push forward
until the grille snaps
into place.
Water Supply to Icemaker
(on some models)
Preparing to Move
If your refrigerator has an icemaker, or if you plan to
add an icemaker later, the icemaker will have to be
connected to a cold water line. A water supply kit
containing copper tubing, shut-off valve, fittings and
instructions is available at extra cost from your dealer.
There should be sufficient tubing for the icemaker from
the cold water supply to allow you to move the
refrigerator out from the wall several feet (approximately
8 feet of 1/4” copper tubing in three 10” diameter coils).
Disconnect power cord from wall outlet, remove all
food, and clean and dry the interior.
Secure all loose items such as grille, shelves and
storage pans, by taping them securely in place to
prevent damage.
Be sure refrigerator stays in upright position during
actual moving and in van. Refrigerator must be
secured in van to prevent movement. Protect the
outside of the refrigerator with a blanket.
Preparing for Vacation
For extended vacations or absences, remove food
For shorter vacations, remove perishable foods
and
and shut off power to the refrigerator. Clean the interior leave controls at regular settings. However, if room
with baking soda solution of one tablespoon of soda to
temperature is expected to drop below
60°F.,
follow
one quart of water. Wipe dry. To prevent odors, leave
same instructions as for extended vacations. Move the
open box of soda in refrigerator. Leave doors open. icemaker feeler arm to the STOP (up) position and be
18
sure to shut off the water supply to the refrigerator.
