Static Pressure (in. wg)
Static Pressure (Pa)
Volume (cfm)
3
Volume (m
/hr )
RPM (Direct)
Density 0.075 lb/ft
3
Density 1.2 kg/m
3
14
Roof Downblast - Exhaust
Direct Drive
G-060 • G-065
Performance certified is for installation type A: Free inlet, Free outlet. Power rating (BHP) does not include transmission losses. Performance ratings include the effects
of a birdscreen. The sound ratings shown are loudness values in hemispherical sones at 5 ft. (1.5 m) in a hemispherical free field calculated per AMCA Standard 301.
Values shown are for installation type A: free inlet hemispherical sone levels.
Damper Size = 8 x 8 (203 x 203)
Roof Opening = 10 x 10 (267 x 267)
Shroud Thickness = 0.064 (1.6)
Motor Cover Thickness = 0.040 (1.0)
Curb Cap Thickness = 0.064 (1.6)
^Approximate Unit Weight = 15 lbs. (7 kg)
All dimensions in inches (millimeters). *May be greater depending on motor.
^Weight shown is largest cataloged Open Drip-Proof motor.
Motor
HP
Fan
RPM
Static Pressure in Inches wg
0 0.05 0.1 0.125 0.15 0.2 0.25 0.3 0.375 0.4
060
E-1/200 1050
CFM
138 116 90 73 53
BHP
0.00 0.00 0.01 0.01 0.01
Sones
1.7 1.7 1.7 1.7 1.7
G-1/100 1300
CFM
170 153 135 125 113 85
BHP
0.01 0.01 0.01 0.01 0.01 0.01
Sones
2.9 2.8 2.8 2.7 2.7 2.6
D-1/60 1550
CFM
203 188 173 166 158 140 120 92
BHP
0.01 0.01 0.01 0.01 0.02 0.02 0.02 0.2
Sones
4.2 3.9 3.8 3.8 3.8 3.7 3.7 3.6
065
E-1/100 1050
CFM
187 161 130 110 87
BHP
0.01 0.01 0.01 0.01 0.01
Sones
2.2 2.1 1.9 1.8 1.7
G-1/60 1300
CFM
231 211 189 178 163 130 92
BHP
0.01 0.01 0.01 0.01 0.01 0.01 0.01
Sones
3.2 3.1 3.0 2.9 2.9 2.8 2.7
D-1/30 1550
CFM
276 259 241 232 223 201 176 145 96
BHP
0.02 0.02 0.02 0.02 0.02 0.02 0.02 0.02 0.02
Sones
4.9 4.6 4.5 4.5 4.4 4.3 4.3 4.1 4.0
E-1050-
RPM G-1300-RPM D-1550-RPM
1
3
⁄4 (44)
19
3
⁄8
(492)
*12
1
⁄8
(308)
17
(432)
3 (76)
Direct Drive RPM
