– 10 –
OPERATION
WARNING: THE APPLIANCE AND ITS PARTS ARE HOT. USE CARE WHEN OPERATING,
CLEANING OR PERFORMING ANY MAINTENANCE.
CONTROLS (Models DGC5, HGC5 and HGC5X — Without Cook & Hold)
COOK TEMPERATURE
HI
LO
POWER
OFF
HEAT
ON
IGNITION
COOL DOWN
ON
OFF
45
50
55
60
40
35
30
25
20
15
10
5
0
COOK TIME
ON
OFF
LIGHTS
FAN
LO
FUNCTION
150
150
225
250
275
300
325
350
375
200
400
425
450
250
475
500
F
100
C
PL-53535
COOK TEMPERATURE
HI
LO
POWER
OFF
HEAT
ON
IGNITION
COOL DOWN
ON
COOK TIME
ON
OFF
LIGHTS
FAN
LO
FUNCTION
150
150
225
250
275
300
325
350
375
200
400
425
450
250
475
500
F
100
C
PL-53541
1
2
3
4
5
0
Power Switch — Turns oven control circuits ON or OFF; COOL DOWN allows the fan motor
to run with the doors ajar to speed oven cooling.
On Light (Amber) — Is lit when Power switch is ON.
Heat Light (White) — Comes on and goes off when the burner cycles on and off.
Ignition Light (Red) — Comes on if burner fails to ignite. When lighting the oven, the IGNITION
light flashes.
Cook Temperature — Controls oven temperature during cooking operation.
Cook Time
(1 Hr. or 5 Hr.) — Sets the bake time. Buzzer sounds continuously after timer counts down
to 0. Oven does not turn off. Turn Cook Time to OFF to stop buzzer. When
oven is not in use, keep Cook Time at OFF position.
Fan Switch — Allows you to select HI or LO Fan speed.
Lights Switch — Turns the lights in the oven ON or OFF.
