I. Specification
We reserve the right to make changes in specifications and design without prior notice.
AC SUPPLY VOLTAGE 115/60/1
AMPERAGE 1.4 A
MINIMUM CIRCUIT AMPACIT
Y
15 A
MAXIMUM FUSE SIZE 15 A
APPROXIMATE ELECTRIC CONSUMPTION 110 W
APPROXIMATE STORAGE CAPACITY 130 lbs (60 Kg)
APPROXIMATE ICE DISPENSING SPEED 20 lbs/min (9 kg/min)
EXTERIOR DIMENSIONS ( W x D x H ) 22" x 30" x 53" (560 x 757 x 1346 mm) With 6" Legs
INTERIOR DIMENSIONS ( W x D x H ) 15.3" x 22.4" x 22.5" (389 x 569.5 x 571 mm)
EXTERIOR FINISH Plastic/SUS Front Cover, P.V.C Galvanized Steel Side Panels
Galvanized Steel Rear Panel
INTERIOR FINISH Polyethelene 1 pc. Mold
INSULATION Polyurethane Foam
WEIGHT Net 178.4 lbs (81 kg), Shipping 220 lbs (100 kg)
CONNECTIONS - ELECTRIC Permanent Connection
- DRAIN Outlet 3/4" FPT
- WATER INLET N/
A
GEAR MOTOR 60 W
AGITATOR Stainless Steel Round Bar 14.5" Dia.
GEAR MOTOR PROTECTION Thermal Protector (Internal)
SAFTEY PROTECTION Interlock Switch for Front Panel
Saftey Switch for Ice Spout
ACCESSORIES - OPTIONAL 6" Legs, 4 pcs
OPERATING CONDITIONS VOLTAGE RANGE 104 - 132 V
AMBIENT TEMP. 45 - 100° F
ENG F-003.0.1196
