GATE RESTRICTOR PLATE AND ADJUSTMENT
The rate at which ice is dispensed can be adjusted by varying the opening of the gate restrictor plate as
illustrated in FIGURE 1. Reducing the dispense rate of ice is especially desirable when using glasses or
other containers with small openings. To adjust the gate restrictor plate, loosen the (4) nuts that hold the
ice chute assembly to the bin. The restrictor plate can now be moved up or down. When the restrictor
plate is fully up, the ice gate opening is 2-1/2” in height, and the maximum rate of ice dispense is
available (approximately 3 oz/sec). Retighten the (4) nuts to set the desired restrictor plate opening. DO
NOT EXCEED 50 IN-LB of torque.
FIGURE 1. Gate Restrictor Plate
NOTE: Tighten (4) nuts for fastening lower ice chute in place to 50 in-lbs (max). Draw all four nuts
tight uniformly.
