Kenmore 106.57022601 Refrigerator User Manual



FREEZER FEATURES
Your model may have some or all of these features. Features that
can be purchased separately as product accessories are labeled
with the word "Accessory." Not all accessories will fit all models.
If you are interested in purchasing one of the accessories, please
call the toll-free number on the cover or in the "Accessories"
section.
!!:::
To Remove and Replace the Shelf:
1. Lift the shelf up and off of the supports to remove it.
2. Replace the shelf by placing it in the supports. Check to be
sure the shelf is securely in place.
Frozen Food Storage Guide
Storage times will vary according to the quality and type of food,
the type of packaging or wrap used (should be airtight and
moisture-proof), and the storage temperature. Ice crystals inside
a sealed package are normal. This simply means that moisture in
the food and air inside the package have condensed, creating ice
crystals.
Put no more unfrozen food into the freezer than will freeze within
24 hours (no more than 2 to 3 Ibs of food per cubic foot [907 to
1,350 g per 28 L] of freezer space). Leave enough space in the
freezer for air to circulate around packages. Be careful to leave
enough room for the door to close tightly.
For more information on preparing food for freezing, check a
freezer guide or reliable cookbook.
The freezer basket or bin can be used to store bags of frozen
fruits and vegetables that may slide off freezer shelves.
To Remove and Replace the Freezer Basket or Bin:
1. Remove the basket or bin by sliding it out to the stop.
2. Lift the front to slide the basket or bin out the rest of the way.
DOOR FEATURES
Your model may have some or all of these features. Features that
can be purchased separately as product accessories are labeled
with the word "Accessory." Not all accessories will fit all models.
If you are interested in purchasing one of the accessories, please
call the toll-free number on the cover or in the "Accessories"
section.
To Remove and Replace the Bin:
1. Remove the bin by pulling out on the tabs behind the basket
to release it from the door liner.
2. Replace the bin by aligning the tabs with the buttons on the
sides of the door liner. Firmly snap the tabs onto the buttons
as shown.
Cool air from the freezer is directed to the door bin directly
beneath the vent.
NOTE: The dairy compartment and can rack are not chilled.
Chilled Door Bin Control
The chilled door bin control is located on the left-hand side of the
refrigerator compartment.
3. Replace the basket or bin by positioning it on the rails. Lift the
basket or bin front slightly while pushing it in fully past the
stops.
16
