OVEN DOOR PARTS
3
For Models: KEBC167MSS00
(Stainless Steel)
8186173
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 8300152 Door Liner
2 Hinge, Door
8300579 R.Side (Orange)
8300580 L.Side (Orange)
4449743 Screw
3 4449259 Glass, Inner
4 8300797 Insulation, Door
7 4449263 Glass, Inner
4449809 Screw
12 8302468 Door Glass, Assy
13 4455852 Door Handle
14 Bracket, Handle
4455803 Stainless Steel
4455804 Stainless Steel
3196184 Screw
19 8301089 Shield, Heat
4449809 Screw
20 8300190 Retainer, Glass
4449809 Screw
21 8300153 Seal, Door Top
23 4451432 Retainer, Clip
