FREEZER DOOR PARTS
16
For Model: KSSS42MDX05
4394682
Illus. Part
No. No. DESCRIPTION
1 2003877 Freezer Door
Panel (Includes
Insulation)
2 2004520 Spacer−Door,
Top
3 2004524 Hinge, Bottom
4 489282 Screw
5 2004521 Hinge, Top
6 2004881 Retaining Ring
Door−Closure
7 1112533 Gasket Retainer,
Side (2)
8 1112540 Gasket Retainer,
Top & Bottom
9 2000879 Door Gasket,
Magnetic
10 486194 Screw (34)
11 2003681 Handle, Door
12 2001230 Washer
13 2004549 Door, Spacer
14 487052 Screw
15 2005020 Trim (Top)
17 2004561 Trim (Bottom)
18 2003677 Trim (Side)
19 2000178 Interior Door
Panel
20 2003128 Shelf Bin (4)
21 939101 Screw Anchor
