AIR FLOW AND RESERVOIR PARTS
22
For Model: KSSS42MDX05
4394682
Illus. Part
No. No. DESCRIPTION
1 2003200 Fan Motor
2 2002732 Cup, Clearance
3 2169142 Fan Blade
4 548263 Bracket (Double)
5 938224 Bracket (Single)
6 548268 Grommet
7 486194 Screw
8 2003925 Deflector,
Air Duct
9 488500 Screw, Ground
10 488366 Clamp, Tube
11 489348 Clamp, Nylon
12 2001145 Channel, Wiring
13 1112871 Fastner
14 2000783 Scroll, Fan
15 2003928 Deflector,
Air Duct
16 488772 Screw
17 2004906 Assembly, Air Duct
18 2000048 Air Deflector,
Icemaker
22 1112869 Gasket, Air Baffle
23 2003576 Cover, Air Outlet
25 2005036 Cover, Evaporator
26 2000795 Connector, Meat
Pan Duct
27 487539 Screw
28 1112840 Baffle, Evaporator
29 1112852 Diffuser, Air Duct
30 2004947 Reservoir
31 488280 Screw
42 Evaporator,
Cover Rail
2000686 Left Side
2000685 Right Side
45 2001337 Gasket (2)
Evaporator Cover
46 2001079 Gasket (2)
47 2001080 Gasket
48 2001081 Gasket
