The exact positions of the spring
clamps and the support bars (for
beveled cooktops only) are shown in
the "Installation dimensions" of each
unit.
Facet cooktops:
A special sealing strip ensures the
slip-proof seating of the cooktop in
the cutout. The gap between the
frame and the countertop will narrow
after a little time has passed.
^
Create the countertop cutout as
shown in the "Installation
dimensions". Observe the safety
distances (see "Installation Safety
Instructions").
Wood or solid surface countertop
^
Seal the cut surfaces with a suitable
sealant to avoid swelling caused by
moisture.
The materials used must be heat
resistant.
Ensure that these materials do not
get on the top surface of the
countertop panels.
^
Position the spring clips and the
securing strips (supplied with the
appliance; only for facet cooktops)
on the top edge of the cut-out
^
Attach the spring clips a and the
securing strips b with the
3.5 x 25 mm wood screws (supplied).
Installation
30
