LE (ALE)
ORDERING INFORMATION
TYPES
1. Standard type
❍: Input the following letter. Class B: B, Class F: F
2. High sensitive type
❍: Input the following letter. Class B: B, Class F: F
COIL DATA (at 20°C 68°F)
1. Standard type
Contact
arrangement
Coil voltage,
V DC
TMP type/PCB side
three terminals
(includes one
dummy terminal)
TMP type/PCB side
three terminals
TMP type/PCB side
four terminals
PCB type
(No tab terminals)
Part No. Part No. Part No. Part No.
1 Form A
5 ALE12❍05 ALE13❍05 ALE14❍05 ALE1P❍05
6 ALE12❍06 ALE13❍06 ALE14❍06 ALE1P❍06
9 ALE12❍09 ALE13❍09 ALE14❍09 ALE1P❍09
12 ALE12❍12 ALE13❍12 ALE14❍12 ALE1P❍12
18 ALE12❍18 ALE13❍18 ALE14❍18 ALE1P❍18
24 ALE12❍24 ALE13❍24 ALE14❍24 ALE1P❍24
48 ALE12❍48 ALE13❍48 ALE14❍48 ALE1P❍48
Contact
arrangement
Coil voltage,
V DC
TMP type/PCB side
three terminals
(includes one dummy
terminal)
TMP type/PCB side
three terminals
TMP type/PCB side
four terminals
PCB type
(No tab terminals)
Part No. Part No. Part No. Part No.
1 Form A
(High sensitivity:
200mW)
5 ALE72❍05 ALE73❍05 ALE74❍05 ALE7P❍05
6 ALE72❍06 ALE73❍06 ALE74❍06 ALE7P❍06
9 ALE72❍09 ALE73❍09 ALE74❍09 ALE7P❍09
12 ALE72❍12 ALE73❍12 ALE74❍12 ALE7P❍12
18 ALE72❍18 ALE73❍18 ALE74❍18 ALE7P❍18
24 ALE72❍24 ALE73❍24 ALE74❍24 ALE7P❍24
48 ALE72❍48 ALE73❍48 ALE74❍48 ALE7P❍48
Nominal voltage,
V DC
Pick-up voltage,
V DC (max.)
(at 20°C 68°F)
Drop-out voltage,
V DC (min.)
(at 20°C 68°F)
Coil resistance,
Ω (±10%)
(at 20°C 68°F)
Nominal operating
current, mA
(±10%)
(at 20°C 68°F)
Nominal operating
power, mW
(at 20°C 68°F)
Maximum
allowable voltage,
V DC
(at 20°C 68°F)
5 3.75 0.25 63 80
400
7.25
6 4.5 0.3 90 66.7 8.7
9 6.75 0.45 203 44.4 13.05
12 9 0.6 360 33.3 17.4
18 13.5 0.9 810 22.2 26.1
24 18 1.2 1,440 16.7 34.8
48 36 2.4 5,760 8.3 69.6
2B121AEx. LE
Product name
LE
Contact arrangement
1: 1 Form A (400 mW)
7: 1 Form A (200 mW)
Terminal shape
2:
3:
4:
P:
TMP type/PCB side three terminals
(includes one dummy terminal)
TMP type/PCB side three terminals
TMP type/PCB side four terminals
PCB type (No tab terminals)
Coil insulation class
B:
F:
Class B insulation
Class F insulation
Coil voltage, V DC
05: 5
06: 6
09: 9
12: 12
18: 18
24: 24
48: 48
UL/CSA, TÜV, VDE approved type is standard (TMP type). SEMKO approved types are also available, please consult us.
UL/CSA, VDE approved type is standard (PCB type).
Note: Standard packing; Carton: 100 pcs. Case 500 pcs.
