PREVENTATIVE MAINTENANCE
18 L20-332, rev. 1 (05/11)
3. PREVENTATIVE MAINTENANCE
3.1. DAILY PREVENTATIVE MAINTENANCE
Performing the preventative maintenance steps below on a daily basis will keep your equipment safe
and at peak performance. During the cooking process, oil/shortening may spill and splatter and
requires immediate attention. Furthermore, during the cooking process, particles, crumbs and
crackling collect inside the cooker tank reducing product quality and decreasing oil/shortening life. If
you are producing high quantities of fried food and/or frying heavily battered food, it may be
necessary to perform these steps more then once a day.
3.1.1. FILTERING WITH A FILTER DRAWER (IF EQUIPPED)
Refer to the following procedure to filter when the appliance is equipped with a filter drawer.
1. Turn the appliance OFF.
2. Pull the blue drain handle down to drain oil/shortening from the cooker tank into the filter pan.
3. Pull the red handle to turn the pump on to circulate oil/shortening through the filter media.
4. To refill the tank, lift the blue drain handle up.
5. When the tank has completed filling, push the red handle to deactivate the pump.
6. Assure that the oil/shortening level is above the minimum level line. Additional oil may need
to be added to the cook tank.
7. The oil/shortening in the cooker tank has now been filtered.
8. Replace the filter media and clean the filter pan following the procedures mentioned in this
manual.
3.1.2. FLUSH HOSE OPERATION (IF EQUIPPED)
The cooker tank can be rinsed cleaned by using a filter flush hose (if equipped). Refer to the
following procedure to operate the filter flush hose.
1. Turn the appliance OFF.
2. Pull the blue drain handle down to drain oil/shortening from the cooker tank into the filter pan.
3. Connect the filter flush hose to the quick connecting fitting.
4. Point the filter hose nozzle outlet into the cooker tank.
5. Pull the yellow handle to turn the pump on and allow oil/shortening to flow through the flush
hose.
6. To refill the tank, lift the blue drain handle up.
7. When the tank has completed filling, push the yellow handle to deactivate the pump.
WARNING
Filtering may require contact with hot surfaces. Wear oil proof
insulated gloves while performing any filtering operation. Serious
injury could result from direct contact with hot surfaces and/or oil.
