Exploded Parts-VF35 Gas Model
L22-382 Rev 1 (8/14)
8
ITEM# PART# PART DESCRIPTION
1 60125901 TUBE, VENT GAS VALVE
2 60127601 FITTING,ADAPTER FEMALE SWIVEL X 1/2 MPT
3 A8029001-C PIPING, VALVE SHIELD
4 60127401 FITTING, ELBOW MALE FLARE X MPT
5 P0007300 SCREW, 8-32 X 1/4 HEX HEAD SLOTTED ZN
6 A8029105 COUPLING, GAS SUPPLY SHORT SG, MKG
7 60128101 VALVE, GAS SUPPLY SHUTOFF
8 60128015 TUBING, FLEXIBLE WITH FITTINGS 22 GAS
60125201-C VALVE, GAS VS820 NAT
60125202-C VALVE, GAS VS820 LP
10 A8035302 PIPING, PILOT BRACKET SG14 SG14R
60128801 PILOT, REVERSE STANDING NAT SG
60128802 PILOT, REVERSE STANDING LP SG
12 60119001 TUBE, FLEXIBLE WITHOUT FITTINGS 18 X 1/4 OD
13 60088001 SCREW, 10-32 X 1/4 HEX HEAD SST
14 PP10084 SWITCH, HI-LIMIT LCM05030
15 A8028601-C PIPING, BRACKET HI-LIMIT-THERMOSTAT SG MILLIVOLT
16 60125501 THERMOPILE, MILLIVOLT
17 P0190700 CLIP, CANOE FASTEX
18 PP10539 KNOB, THERMOSTAT WITH OFF, 200-400F & 100-200C
19 PP10687 SCREW, 6-32 X 313 THRUSS HEAD PHILLIPS ZN
20 B6744401 WIRING, MILLIVOLT HI-LIMIT & THERMOSTAT SG
21 60125401 THERMOSTAT, RX MILLIVOLT 200-400F
9
11
D) GAS TRAIN
Gas Train Drawing Parts List
