WARNING- THIS APPLIANCE MUST BE EARTHED
This appliance is designed to operate from a mains supply of AC230V ~ 50HZ.
Check that the voltage marked on the product corresponds with your
supply voltage.
This product is fitted with a 13A plug complying with BS1363.
If this plug is unsuitable or needs to be replaced, please note
the following:Important: The wires in the mains lead are
Coloured in accordance with the following code:
GREEN/YELLOW-EARTH
BLUE-NEUTRAL
BROWN-LIVE
For UK use only – Plug fitting details (where applicable):
As the colours of the wires in the mains lead of this appliance may not correspond with
the coloured markings identifying the terminals in your plug, proceed as follows:
The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which
is marked with the letter E or by the earth symbol or coloured GREEN or
GREEN/YELLOW.
The BLUE wire is the NEUTRAL and must be connected to
the terminal marked with the letter N or coloured BLACK.
The BROWN wire is the LIVE wire and must be connected to
the terminal marked with the letter L or coloured RED.
Always ensure that the plug cord grip is fastened correctly.
If a 13A (BS1363) fused plug is used it must be fitted with a
13amp fuse conforming to BS1362 and be BSI or ASTA
approved.
If your appliance is supplied with a non-rewireable plug fitted to the mains lead you will
find that it incorporates a fuse, the value of which is indicated either on the base of the
plug or on the fuse carrier. Should the fuse need replacing, you must use an ASTA
approved fuse (conforming to BS1362) of the same rating. If the fuse cover is lost the
plug must not be used until a replacement is obtained from an electrical supplier. If you
need to remove the plug, cut it from the mains lead and dispose of it. Never attempt to
re-use this plug or insert it into a socket outlet, as there is a very great risk of an
electric shock.
SPECIFICATIONS:
Rated voltage: 230V~50Hz,
Operating frequency: 2,450MHz
Power output: 700W
Outside Dimensions: 452mm(W) x 360mm (D) x 262mm(H)
Oven capacity dimensions 315mm(W) x 279mm (D) x 210mm(H)
Oven Capacity: 17 Litres
Weight:Approx. 10.5kg
Connection to the mains supply
9
Non-rewireable mains plug
