3
INSTALLATION
REQUIREMENTS
Tools and Parts
IMPORTANT:
■ Observe all governing codes and ordinances.
■
Installer: Leave Installation Instructions with homeowner.
■ Homeowner: Keep Installation Instructions for future
reference and for the local electrical inspector’s use.
■ Keep cardboard shipping piece or plywood under
refrigerator until it is installed in the operating position.
■
Comply with installation specifications and dimensions.
■ Remove any moldings or decorative panels that prevent
the refrigerator from being serviced.
■ Contact a qualified electrical installer.
Tools needed:
Make sure that you have the tools necessary for proper
installation:
Parts needed:
■
Your refrigerator dealer has a kit available with a ¹⁄₄ in.
(6.35 mm) saddle-type shut-off valve, a union, and copper
tubing.
■ Or you can purchase a ¹⁄₄ in. (6.35 mm) copper tubing with
shutoff valve and a ¹⁄₄ in. (6.35 mm) compression fitting
(coupling).
■
Depending on water line connections, you may also need
a ¹⁄₄ in. (6.35 mm) nut and ¹⁄₄ in. (6.35 mm) ferrule.
Product Dimensions
Top View
1. Dimensions may vary based on model
Side View
Front View
■ Hand drill or electric drill
(properly grounded)
■ ⁷⁄₁₆ in. and ¹⁄₂ in. open-end
wrenches
■ ¹⁄₄ in. nut driver and
drill bit
■ Two adjustable wrenches
■
Standard screwdriver
■
Socket wrench
23
5
/
8"
(60.0 cm)
27
1
/
4"
(69.2 cm)
29
3
/
8"
(74.6 cm)
35
1
/
2"
(90.2 cm)
1
15
1
/
2"
(39.4 cm)
19
1
/
2"
(49.5 cm)
2
3
/
8"
(6.0 cm)
1. Dimensions shown from floor with rollers set
at minimum height
2. Overall cabinet height with rollers at
maximum height
3. Minimum height
21
1
/
8
"
(53.7 cm)
71
1
/
2
"
(181.6 cm)
56
1
/
8
"
(142.6 cm)
1
/
4
" (6.4 mm)3
5
/
8
" (9.2 cm)
71
3
/
4
"
(182.2 cm)
71
7
/
8
"
(182.5 cm)
1
2
3
35
11
/
16
"
(90.6 cm)
67
7
/
8
"
(172.5 cm)
3
5
/
8
"
(9.2 cm)
