Whirlpool 9762363A Range User Manual



12
When the cook time ends or the last step of the sequence is
complete, the display will show a warming countdown time.
When warming ends, the oven will automatically shut off and
End will appear on the display. Four tones will sound, and then
four 1-second reminder tones will sound every minute thereafter.
To Disable Automatic Warm Hold: Press and hold WARM for
5 seconds. Off will appear in the 4-digit display. Repeat to turn
back on.
When using the Automatic Warm Hold Feature, cook times may
need to be adjusted accordingly so that foods do not become
overcooked and dry.
To Use Manual Warm Hold Feature:
1. Press WARM.
2. Set the temperature (optional).
Press the TEMP up or down arrow pad to raise or lower
the temperature in 5°F (3°C) amounts to set a temperature
other than 150°F (66°C). The warm range is 100°F-200°F
(38°C-93°C).
3. Press START.
4. Press OFF/CANCEL when finished.
Timed Cooking
(on some models)
Timed Cooking allows the oven to be set to turn on at a certain
time of day, cook for a set length of time, and/or shut off
automatically. Delay start should not be used for food such as
breads and cakes because they may not bake properly.
Style 1 - Series Electronic Controls (see Electronic Oven
Controls section)
To Set a Timed Cook:
1. Press BAKE (optional).
2. Press the TEMP up or down arrow pads to enter a
temperature other than the one displayed.
3. Press STOP TIME.
4. Press the HR and MIN up or down arrow pads to enter
the desired time to end cooking.
5. Press START. The display will count down the time.
When the time ends, the oven will shut off automatically and
End will appear on the display. End-of-cycle tones will
sound, then, if enabled, reminder tones will sound every
minute.
6. Open and close the oven door to clear the display and/or
stop reminder tones.
To Set a Delayed Timed Cook:
Before setting, make sure the clock is set to the correct time of
day. See Clock section.
1. Press desired cook function.
2. Press the TEMP up or down arrow pads to enter a
temperature other than the one displayed.
3. Press START TIME or DELAY START TIME.
4. Press the HR and MIN up or down arrow pads to enter
the time of day to start.
5. Press STOP TIME (optional).
6. If STOP TIME has been pressed, press the HR and MIN up
or down arrow pads to enter the desired time to end
cooking.
7. Press START. DELAY will appear on the display.
When the start time is reached, the oven will automatically
turn on. When the stop time is reached (if programmed), the
oven will shut off automatically and End will appear on the
display. End-of-cycle tones will sound, then, if on, reminder
tones will sound every minute.
8. Open and close the oven door to clear the display and/or
stop reminder tones.
Style 2 - Series Electronic Oven Control (see Electronic
Oven Controls section)
To Set a Timed Cook:
1. Press BAKE. The bake indicator light will light up.
2. Set the temperature (optional).
3. Press the TEMP/TIME up or down arrow pad to enter a
temperature other than the one displayed.
4. Press COOK TIME. The cook time oven indicator light will
light up.
5. Press TEMP/TIME up or down arrow pad to enter the
length of time to cook.
6. Press START/ENTER. The display will count down the time.
When the time ends, the oven will shut off automatically and
End will appear on the display.
7. Press CANCEL or OFF/CANCEL or open the oven door to
clear the display.
To Set a Delayed Timed Cook:
Before setting, make sure the clock is set to the correct time of
day. See Clock section.
1. Press BAKE.
2. Set the temperature (optional).
3. Press the TEMP/TIME up or down arrow pad to enter a
temperature other than the one displayed.
4. Press COOK TIME. The cook time oven indicator light will
light up.
5. Press the TEMP/TIME up or down arrow pad to enter the
length of time to cook.
6. Press START TIME. The start time/delay oven indicator light
will light up.
7. Press the TEMP/TIME up or down arrow pad to enter the
time of day to start.
8. Press START/ENTER.
When the start time is reached, the oven will automatically
turn on. The temperature and/or time settings can be
changed any time after pressing START/ENTER by repeating
steps 1-7. When the set cook time ends, the oven will shut off
automatically and End will appear on the display.
9. Press CANCEL or OFF/CANCEL or open the oven door to
clear the display.
WARNING
Food Poisoning Hazard
Do not let food sit in oven more than one hour before
or after cooking.
Doing so can result in food poisoning or sickness.
