Whirlpool WRX735SDBM Refrigerator User Manual



12
3. Press and release the water dispenser paddle, as needed, to
dispense water to the 1 cup fill line.
NOTE: If overfilling or spilling occurs, discard the water and
press ICE TYPE “Back” to restart the calibration process.
4. When 1 cup of water has been correctly dispensed into the
measuring cup, press the MEASURED FILL button under the
word “Confirm” to confirm the calibration.
5. When Measured Fill calibration has been confirmed the icons
will disappear and the display will return to the home screen.
The Water Dispenser
IMPORTANT: Dispense at least 1 qt (1 L) of water every week to
maintain a fresh supply.
To Dispense Water (Standard):
1. Press a sturdy glass against the water dispenser lever.
NOTE: While dispensing water and for 3 seconds after
dispensing has stopped, the digital display will show how
much water has been dispensed.
2. Remove the glass to stop dispensing.
To Dispense Water (Measured Fill):
Measured Fill allows you to dispense a specified amount of water
with the touch of a few buttons.
NOTE: The amount of water you select will be dispensed. Be sure
that the container is empty and can hold the entire volume. If ice is
in the container, you may need to adjust your selection.
1. Press MEASURED FILL to turn the feature on. When the
feature is on, the Measured Fill screen appears on the display.
Press ICE TYPE to manually turn off the Measured Fill feature.
NOTE: The dispenser will automatically turn off Measured Fill
after 1 minute of inactivity. When Measured Fill is turned off,
any changes you have made will be lost and all defaults will be
restored.
2. You can dispense water by the ounce, cup, or liter. The default
unit is ounces. To switch to cups or liters, press the LIGHT
button.
Default, minimum, and maximum volumes are listed below.
3. Press the LOCK and OPTIONS buttons to adjust the volume
as desired. The LOCK button increases the volume, and the
OPTIONS button lowers the volume.
NOTE: Most coffee cups (commonly 4 to 6 oz [118 to 177 mL]
per cup) are not the same size as a measuring cup (8 oz
[237 mL]). You may need to adjust the volume to avoid
unintentionally overfilling coffee cups.
4. To dispense water, press a sturdy glass against the water
dispenser lever OR place the glass below the water dispenser
and press the MEASURED FILL button.
NOTE: While dispensing water, the digital display will count
down how much water remains to be dispensed, according to
the volume you selected. The flow of water will automatically
stop once the desired volume has been dispensed.
5. To stop dispensing before the selected volume has been
dispensed, remove the glass from the dispenser lever OR
press the MEASURED FILL button a second time.
NOTE: If you stop dispensing before the desired volume has
been dispensed, the digital display will continue to show how
much water remains to be dispensed. The display will turn off
after 1 minute of inactivity.
To select a new volume or start dispensing the same volume
again, you must first finish dispensing the selected volume, or
turn off the Measured Fill feature (either by waiting 1 minute so
it will automatically turn off or by pressing ICE TYPE to
manually turn it off) and then turn it back on.
A.1 cup of water
A
Units Default Minimum Maximum
Ounces 8 1 128
Cups 1 ¹/ 16
Liters 0.25 0.05 4.00
