Planning Information
48" (1219) Dual Fuel Ranges
MODELS DF486C, DF486G, DF484CG, DF484DG AND DF484F
Dimensions in parentheses are in
millimeters unless otherwise specified.
3
MODEL OPTIONS
Six Burners/Charbroiler DF486C
Six Burners/Griddle DF486G
Four Burners/Charbroiler
and Griddle DF484CG
Four Burners/Double
Griddle DF484DG
Four Burners/French Top DF484F
Natural gas models listed, for LP gas add
(-LP) to the model number.
VENTILATION OPTIONS
48" (1219) Pro wall or wall
chimney hood or liner
54" (1372) Pro wall, wall chimney
or island hood or liner
Also refer to the Pro Ventilation section of
our website, wolfappliance.com.
ACCESSORIES
5" (127) and 10" (254) classic
stainless steel risers
20" (508) classic stainless steel
riser with shelf
Red or black control knobs—
must be ordered with the range
Chrome or brass bezels
One-piece wok grate and single
burner grate
Porcelain-cast two-burner S-grates
Two-piece broiler pan and temper-
ature probe
Set of three oven racks
Hardwood cutting board—griddle
models only
Bake stone accessory
Dehydration accessory
Front leg extension covers and
rear leg caster covers
High altitude conversion kit
Accessories are available through your
Wolf dealer. To obtain local dealer
information, visit the Showroom Locator
section of our website, wolfappliance.com.
SPECIFICATIONS
Overall Range Width 47
7
/8" (1216)
Overall Range Height
(to cooking surface)
36
7
/8" (937)
Overall Range Depth 29
1
/2" (749)
Dual-Stacked Sealed Surface Burners
15,000 Btu/hr (4.4 kW) burners with 950 Btu/hr
(.3 kW) delivered at simmer
Single 9,200 Btu/hr (2.7 kW) burner with 325 Btu/hr
(.1 kW) delivered at simmer
Infrared Charbroiler 16,000 Btu/hr (4.7 kW)
Infrared Griddle
Natural Gas 15,000 Btu/hr (4.4 kW)
LP Gas 13,000 Btu/hr (3.8 kW)
Double Griddle (two burners)
Natural Gas 15,000 Btu/hr (4.4 kW)
LP Gas 13,000 Btu/hr (3.8 kW)
French Top 15,000 Btu/hr (4.4 kW)
Overall Interior Capacity (large oven) 4.5 cu ft (127 L)
Overall Interior Dimensions 25"W x 16
1
/2"H x 19"D
(large oven) (635 x 419 x 483)
Usable Interior Dimensions 21
1
/2"W x 16
1
/2"H x 16
3
/8"D
(large oven) (546 x 419 x 416)
Overall Interior Capacity (small oven) 2.5 cu ft (71 L)
Overall Interior Dimensions 14"W x 16
1
/2"H x 19"D
(small oven) (356 x 419 x 483)
Usable Interior Dimensions 11
5
/8"W x 16
1
/2"H x 16
3
/8"D
(small oven) (295 x 419 x 416)
Opening Width 48" (1219)
Electrical Supply Requirements 240/208 V AC, 60 Hz
50 amp circuit
Electric Rating 10.2 kW at 240 V
8.8 kW at 208 V
Total Amps 42.5
Shipping Weight 665 lbs (302 kg) – 750 lbs (340 kg)
Specifications are subject to change without notice.
IMPORTANT NOTE: A minimum 10" (254) riser is required for all
48" (1219) dual fuel range models installed against a combustible
surface.
