DESCRIPTION OF THE APPLIANCE
A
B
C
D
E
F
G
I
H
33
66
99
1212
A- Thermostat control
B- Dairy compartment
C- Storage shelf
D- Bottle storage shelf
E- Compartment for storing frozen food
F- Compartment for freezing fresh food
G- Salad drawers
H- Glass shelf
I- Wire shelves
17
Door Reversal
1. Disconnect from the electricity supply.
2. Remove all loose items, including food, store food
in a cool place.
3. Gently lay the fridge/freezer on its back with the
top held away from the floor by 5-8 cm (2-3
inches) of packing;
4. Remove the feet (2-3)
5. Remove bottom hinge (1).
6. Remove the freezer door by releasing it from the
middle hinge (H).
7. Unscrew the middle hinge.
8. Slide out the fridge door from pin (G), unscrew
the latter and then screw it down into the hinge
hole provided on the opposite side, after having
removed the small plugs (I) which should then be
fitted on the opposite side.
9. Refit the fridge door and replace the middle hinge
to the left hand side.
10.Replace the door and bottom hinge (1) on the
opposite side.
11.Refit the feet (2-3) on the opposite side.
Attention
After completion of the door reversing operation,
check that the door gasket adheres to the cabinet. If
the ambient temperature is cold (i.e. in Winter), the
gasket may not fit perfectly to the cabinet. In that
case, wait for the natural fitting of the gasket or
accelerate this process by heating up the part
involved with a normal hairdryer on a low setting.
G
H
I
I
I
D715 PIED/M
1
2
3
