12
Stainless Steel Surfaces
Clean stainless steel surfaces with a mild solution of
detergent and warm water. Rinse and dry with a soft, lint-
free cloth.
You may also use Dacor Stainless Steel Cleaner on the
stainless steel surfaces. Use it according to the directions
on the package.
Brass, Chrome and Copper Surfaces
Using a soft cloth, clean metal surfaces with a mild solution
of detergent and warm water. Rinse and dry with a soft,
lint-free cloth.
Cleaning the Griddle
Clean the griddle after each use. Wash it thoroughly in
hot soapy water to avoid stains from grease build-up.
The griddle is coated with a non-stick coating for easy
cleaning. Warm water and liquid detergent are all that are
needed for cleaning. Remove stubborn spots with a non-
abrasive plastic mesh pad. To prevent scratching, do not
use abrasives or abrasive cleaners. Use the soft side of a
sponge to scrub it. Dry it with a lint-free cloth.
CAUTION
Always wipe stainless steel (silver colored) surfaces
with the grain. To prevent scratching, do not use
abrasive cleaners or scrubbers on stainless steel
surfaces.
•
CAUTION
Always wipe stainless steel (silver colored) surfaces
with the grain. To prevent scratching, do not use
abrasive cleaners or scrubbers on stainless steel
surfaces.
•
CAUTION
To prevent scratching, do not use abrasive cleaners
or scrubbers on metal surfaces.
•
CAUTION
To prevent scratching, do not use abrasive cleaners
or scrubbers on metal surfaces.
•
Cleaning and Maintenance
Cleaning the Cooktop (cont.)
Burner Components and Igniters
IMPORTANT: The igniter(s) will not work properly if the
burner cap, burner ring, burner base or the igniter itself are
not clean. Dirty or wet igniters may not spark at all.
After dissembling the burners, check for any dirt or grime
deposited on the individual parts, including the igniters.
Using the igniter cleaning brush that came with your
cooktop, brush completely around the igniter, including
over and under the edge of the metal top and porcelain
base. Use care while cleaning because the porcelain
is fragile and can crack or break. Do not use water to
clean the igniters. If necessary, use a small amount of
rubbing alcohol to help dissolve grime
Examine the burner rings. Remove anything stuck in the
holes with a straightened paper clip, wire or needle. Be
careful not to scratch or damage the ring and cap. Do
not distort the shape of the burner ring holes.
Clean all the burner parts, including the burner bases,
with window cleaner or rubbing alcohol. Use a cleaning
brush with plastic bristles or a firm tooth brush. When
done, rinse the parts well with clean water. Dry all the
parts thoroughly before re-assembling them.
Reassemble the cooktop according to the burner and
grate assembly instructions starting on page 6. Test
the burners after reassembling them. If the flame is
uneven, be sure that the brass burner ring and porcelain
burner cap are properly positioned, then check for any
remaining dirt or grime on the burner parts or igniter. If
erratic clicking is still present, make sure the igniter is
completely dry. If the unit still exhibits problems after
drying, call your local Dacor
®
Authorized Service Agent.
1.
2.
3.
4.
Crown Burner Parts
Igniter
Burner
Head
Burner
Ring
Stack Burner Parts
Igniter
Burner
Cap
Burner
Base
Burner
Ring
Burner
Cap
Burner
Base
