Setting Up the Scanner
CRESSON
Rev. C
A5 size CHAP1.fm
2/16/99 Pass 0
L
Proof Sign-off:
M. Fujimori _______
<leadername> _______
<editorname> _______
Setting the terminator switch
The scanner has a built-in terminator, which allows SCSI devices
to communicate properly with each other. You may need to
change the terminator switch setting according to your computer
system.
Note:
Do not use an external terminator.
0
1
2
3
4
5
6
7
SCSI
ID
OPTION
TERMINATOR
SW
LOCK
UNLOCK
ON
OFF
ON
OFF
1
7
2
4
5
6
The terminator switch is located
on the back of the scanner.
Only the scanner is connected
terminator on
