Positioning transparencies for scanning
Note:
❏
Be sure to wipe the Transparency Unit glass, the scanner’s
document table, and the narrow window near the mounting bracket
with a soft cloth before scanning transparencies.
❏
Operation of the Transparency Unit is controlled automatically by
your scanner software.
1. Open the Transparency Unit.
2. Place the transparency guide onto the scanner’s document
table.
See the following pages for details on each of the following
types of transparencies.
35mm film strips ... page 3-8
Mounted slides ... page 3-8
120/220 film ... page 3-9
4 x 5 inch film ... page 3-9
Non-standard film sizes ... page 3-10
3. Place the transparency on the scanner’s glass document table,
aligning it with the upper right-hand corner of the
transparency guide. Make sure the glossy side of the
transparency is facing down.
4. Close the Transparency Unit. If the reflective document mat
is installed on the Transparency Unit, remove it.
Note:
Make sure the Transparency Unit is completely closed. Otherwise an
option error will occur and scanning will be impossible.
Use your scanner software to scan the transparency.
