MTP SW6 • Remote Contol
Remote Control, cont’d
3-12
MTP SW6 • Remote Contol
3-13
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Switch mode
Set normal (manual)
switch mode
1#
F1
]
The user selects inputs manually, from the front panel or
under remote control.
Set auto switch mode 2#
F2
]
The switcher automatically switches to the highest
numbered input with signals present. Manual switching
is disabled.
Lock (executive) modes
Lock front panel
functions
1X
Exe1
]
Enable Lock mode 1.
Unlock front panel
functions
0X
Exe0
]
Enable Lock mode 0.
View lock status X
X1#]
Command/response table for SIS commands (continued)
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Resets
Reset all level and
peaking adjustments
E
ZT
}
Zpt
]
Clear all level and peaking adjustments to their default
(0) values.
Reset all skew
adjustments
E
ZK
}
Zpk
]
Clear all input and output skew values to 0 ns.
Reset audio input levels
E
ZA
}
Zpa
]
Reset all audio input levels (gain and attenuation) to 0 dB.
Reset audio output level
E
ZV
}
Zpv
]
Reset the audio output levels (volume) to 100% (no
attenuation).
Reset whole switcher
E
ZXXX
}
Zpx
]
Clear all ties and presets, reset all audio gains to 0 dB,
and reset volume to 100%.
N
X1#
= Front panel lock 0 = off (unlocked)
1 = on (locked)
Command/response table for SIS commands (continued)
