MTP SW6 • Remote Control
Remote Control, cont’d
3-14
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Information requests
Information request I
V
X!
•A
X!
•F
X1$
•Vmt
X1#
•Amt
X1#
•Exe
X1#]
V (selected video input)•A (selected audio input)• F
(switch mode)•Vmt (video mute — not supported by this
switcher)•Amt (audio mute)•Exe (front panel lock).
Request part number N
68-928-01
]
See appendix A for part numbers.
Query controller
firmware version
Q
X1%]
Example:
Q
1.23
]
The factory-installed controller rmware version is 1.23
(sample value only).
Request system
threshold status
42S
X$]
Command/response table for SIS commands (continued)
N
X!
= Input number
1 – 6
X1$
= Switch mode 1 = normal (manual)
2 = auto
X1#
= Mute, Front panel lock 0 = off
1 = on
X1%
= Firmware version v.vv
X$
= Threshold 0 = outside of threshold
