PSTN disconnect Tone
ON is the period of ringing (“On time” in ‘ms’) while OFF is the period of
silence. In order to set a continuous ring, OFF should be zero. Otherwise it
will ring ON ms and a pause of OFF ms and then repeat the pattern. Up to
three cadences are supported.
Default Ring Cadence This defines the ring cadence for the phone. The default setting is:
c=2000/4000;
MAINTENANCE PAGE DEFINITIONS
Maintenance/Network Settings
Address Type This selects the type of IP address assigned: DHCP, PPPoE or Static IP.
PPPoE When PPPoE is selected, the user needs to enter the following: PPPoE
Account ID, PPPoE Password, PPPoE Service Name.
Static IP When Static IP is selected, the user needs to enter IP address, Subnet
Mask, Default Gateway, DNS Server 1 and DNS Server 2.
Alternate DNS Server This field sets the alternate DNS server for the user.
Layer 3 Qos This field defines the layer 3 QoS parameter. It is the value used for IP
Precedence, Diff-Serv or MPLS. The Default value is 0.
Layer 2 QoS
802.1Q/VLAN Tag
This field contains the value used for layer 2 VLAN tagging. The Default
value is 0.
Layer 2 QoS
802.1p Priority Value
This assigns the priority value of the Layer2 QoS packets. The Default value
is 0.
802.1x Mode This field sets 802.1x Mode. The default value is disabled. If EAD-MD5 is
selected, users will be required to enter Identity and MD5 Password.
Proxy This field sets HTTP Proxy, HTTPS Proxy, FTP Proxy or No Proxy. Using
HTTP Proxy, other protocols can be applied by checking the box “Apply to
Other Protocol”.
Maintenance/Wifi Settings
WiFi Functions This parameter enables/disables the WiFi function. The default setting is set
to “Disable”.
Wireless Mode This parameter defines the wireless mode used. The GXV3175 supports
802.11b/g/n
Network Type This parameter defines the network type of the wireless network: Ad-hoc or
