40 Operating overview EN
The Control Panel Button
Depending on what state the printer is in, pressing the Control Panel Button allows you to control
printing tasks by either starting or resuming a printer function. Use the Control Panel Button to
accomplish the following tasks:
Table 3-2 Control Panel Button usage
Function Lights Action Result
Wake Up All lights are off while
plugged into power source
Briefly push and release the
button.
The printer will wake up to a
ready state.
Self Test Ready (bottom) Light is on
and the other lights are off.
Briefly push and release the
button.
Prints a self-test page.
Printer Reset The Ready (bottom) Light
will remain lit, if there are no
printer errors.
Press and hold the button
until the three Front Panel
Lights blink quickly in
succession.
The reset will return the
printer to the factory default
settings. This clears all data
from memory, including any
downloaded fonts and
macros.
Resume (from Manual
Feed)
The Data (middle) Light
blinks.
Briefly push and release the
button.
Override manual feed to
print from paper cassette.
Continue (from
memory error)
Error (top) Light blinks. Briefly push and release the
button.
Allows the printer to recover
and continue printing the
job.
Form Feed The Data (middle) Light and
the Ready (bottom) Light
both remain on.
Briefly push and release the
button.
The remaining data in
printer memory will print.
