Cisco MDS 9124e 24-port Fabric Switch
Includes: (1) 4Gb SAN Switch; 24 ports enabled (16
server, 8 external); four (4) short wave 4Gb SFPs; SAN-
OS; eight (8) port dust covers; documentation
NOTE:
NOTE: NOTE:
NOTE:
#0D1 will appear after this part number on your
sales order when factory integration is indicated.
AG642A
Virtual Connect Modules
Virtual Connect ModulesVirtual Connect Modules
Virtual Connect Modules
HP 1/10Gb Virtual Connect Ethernet Module for c-Class
BladeSystem
399593-B22
HP 1/10Gb-F Virtual Connect Ethernet Module for c-
Class BladeSystem
447047-B21
HP 4Gb Virtual Connect Fibre Channel Module for c-
Class BladeSystem
409513-B21
Mezzanines and Adapters
Mezzanines and AdaptersMezzanines and Adapters
Mezzanines and Adapters
HP NC325m PCI Express Quad Port 1Gb Server Adapter
for c-Class BladeSystem
416585-B21
HP NC326m PCI Express Dual Port 1Gb Server Adapter
for c-Class BladeSystem
406771-B21
HP NC360m Dual Port 1GbE BL-c Adapter
445978-B21
HP NC364m Quad Port 1GbE BL-c Adapter
447883-B21
HP NC373m PCI Express Dual Port Multifunction Gigabit
Server Adapter for c-Class BladeSystem
406770-B21
HP NC512m Dual Port 10GbE Multifunction BL-c Adapter
NOTE:
NOTE: NOTE:
NOTE:
An NC512m network adapter card is required for
each server blade connecting to the HP 10Gb Ethernet BL-
c Switch.
NOTE:
NOTE: NOTE:
NOTE:
A maximum of one NC512m is supported per
server in a type II mezzanine slot. For more information,
see the Mezzanine Slot Compatibility matrix within the HP
NC512m Dual Port 10GbE Multifunction BL-c Adapter
QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/
12752_div/12752_div.html
NOTE:
NOTE:NOTE:
NOTE:
The NC512m requires 4GB of server memory
440910-B21
QLogic QMH4062 1GbE iSCSI Adapter for HP c-Class
BladeSystem
488074-B21
QLogic QMH2462 4Gb FC HBA for HP c-Class
BladeSystem
403619-B21
Emulex LPe1105-HP 4Gb FC HBA for HP c-Class
BladeSystem
403621-B21
Step 2 - Additional Options (Select each type of required options with quantities specified):
Step 2 - Additional Options (Select each type of required options with quantities specified):Step 2 - Additional Options (Select each type of required options with quantities specified):
Step 2 - Additional Options (Select each type of required options with quantities specified):
Switch Module Options
Switch Module OptionsSwitch Module Options
Switch Module Options
Cisco Catalyst Blade Switch 3120X for HP
451439-B21
Cisco Catalyst Blade Switch 3120G for HP
451438-B21
1000Base SX Fiber SFP Module for the Cisco 3020
Catalyst Blade Switch
378929-B21
HP BLc GbE2c Layer 2/3 Fiber SFP Option Kit
NOTE:
NOTE: NOTE:
NOTE:
Each kit contains two SX SFP fiber modules. Only
SFP modules with this part number will operate in the
GbE2c Layer 2/3 Ethernet Blade Switch.
440627-B21
QuickSpecs
HP BladeSystem c-Class Interconnect Components
HP BladeSystem c-Class Interconnect ComponentsHP BladeSystem c-Class Interconnect Components
HP BladeSystem c-Class Interconnect Components
Options
DA - 12524 Worldwide — Version 11 — July 14, 2008
Page 19
