For Your Safety
INSTALLATION PRECAUTIONS
■ Environment
CAUTION
• Avoid placing the printer on or in locations which are unstable or not level. Such locations may cause the
printer to fall down or fall over. This type of situation presents a danger of personal injury or damage to
the printer. ................................................................................................................................................................
• Avoid locations with humidity or dust and dirt. If dust or dirt become attached to the power plug, clean the
plug to avoid the danger of fire or electrical shock. ...............................................................................................
• Avoid locations near radiators, heaters, or other heat sources, or locations near flammable items, to avoid
the danger of fire. .....................................................................................................................................................
• To keep the printer cool and facilitate changing of parts and maintenance, allow access space as shown
below.
Leave adequate space, especially around the rear cover, to allow air to be properly ventilated out of the
printer........................................................................................................................................................................
Other precautions
• To avoid machine malfunction, do not use the equipment under the following conditions:
• Direct exposure to sunlight
• Extremely high or low temperature [temperature range: 10˚C to 32.5˚C (50˚F to 90.5˚F)]
• Extremely high or low humidity (humidity range: 20% to 80% RH)
• Condensation due to rapid change of temperature
• Areas of poor ventilation
• Areas of high dust or chemical fume concentration (solvent etc.)
• Make sure that the printer is installed in a well ventilated room so as not to increase density of ozone in the air.
Since ozone is heavier than air, it is recommended that air at floor level be ventilated.
• The printer weighs approximately 51 kg (112 lbs.). It must be handled by two people.
■ Power supply/Grounding the printer
WARNING
• DO NOT use a power supply with a voltage other than that specified. Avoid multiple connections in the
same outlet. These types of situations present a danger of fire or electrical shock. ...........................................
Left
Right
Rear
35 cm (13.8”)
Controller Board
Opening Space
45 cm (17.7”)
Multi-Purpose Tray
Opening Space
60 cm (23.6”)
Front cover opening space
50 cm (19.7”)
Media tray Opening
Space
