32 key Numeric-Alpha Key Map
l The following keypad key map is used on an MX7 that is NOT running a Honeywell Terminal Emulator. Terminal
emulators use a separate key map.
l When using a sequence of keys that require an alpha key, first press the Alph key. Use the Shft sticky key or the Caps
key sequence (Blue+Tab) for upper case alphabetic characters.
l Pressing the Alph key forces “Alpha” mode for the 2,3,4,5,6,7,8, and 9 keys. The 1 and 0 keys continue to place a 1 and
0 into the text field.
l To create a combination of numbers and letters before pressing Enter, remember to tap the Alph key to toggle between
Alpha and Numeric mode.
l When using a sequence of keys that do not include the Alph key but does include a sticky key, press the sticky key first
then the rest of the key sequence.
l Pressing the Power key when in any sticky mode (Blue, Orange, Shift, etc) either turns the device On (when Off) or
places it in Suspend (when On).
l For those key maps that require remapping (MAP), keys can be remapped using the Keypad Control Panel (Start >
Settings > Control Panel > Keypad).
To get this Key / Function Press these Keys in this Order
Power / Suspend Power
Field Exit (default is VK_PAUSE)
MAP = Mappable
Blue (MAP) Shft (MAP) Diamond #1
= Orange Shft (MAP)
Diamond#2
Default is Mappable
( Blue Shft (MAP)
Diamond#2
Default is Mappable
! Orange Shft (MAP)
Diamond#3
Default is Mappable
) Blue Shft (MAP)
Diamond#3
Default is Mappable
Volume Adjust Mode Orange Scan
Up Arrow
Down Arrow
Display Backlight Brightness
Adjust Mode
Blue Scan
Up Arrow
Down Arrow
Toggle Alpha Mode Alph
Toggle Blue Mode Blue
Toggle Orange Mode Orange
Toggle Shift Mode Shft
Alt Mode Alt
Control Mode Ctrl
Esc Blue Alt
Space Spc
