Control Panel
Start > Settings > Control Panel ξor My Device > Control Panel link
Note: Change the font displayed on the touch screen by choosing Start > Settings > Control Panel > Keyboard and then the
Key map dropdown list.
Tap the ? button for Help when changing MX7 Control Panel options. Contact Technical Assistance for updates as they
become available.
Option Function
About
Software, hardware, versions and network IP. No user intervention allowed. Integrated
scanner type is identified.
Accessibility
Customize the way the keyboard, audio, display or mouse function for users with
hearing or viewing difficulties.
Administration AppLock Administration utility.
Battery View voltage and status of the main and backup batteries.
Bluetooth Set the parameters for Bluetooth device connections.
Certificates Manage digital certificates used for secure communication.
Date/Time Set Date, Time, Time Zone, and Daylight Savings.
Device Management
Allows a Device Management client (the device equipped with a Microsoft Windows
CE operating system) to work with a Microsoft Systems Management Server.
Dialing Connection setup for modem attached to COM port or Compact Flash slot.
Display
Set background graphic and scheme. Set touch screen and keypad backlight
properties and timers.
Input Panel Select the current key / data input method. Select custom key maps.
Installed Programs
View the list of installed programs. In some OS versions this panel replaced Remove
Programs.
Internet Options
Set General, Connection, Security, Privacy, Advanced and Popups options for Internet
connectivity.
Keyboard Select a Key Map (or font). Set key repeat delay and key repeat rate.
Keypad Configure KeyMap keys, RunCmd and LaunchApp.
License Viewer Displays license information for installed licensed applications.
Mixer
Adjust the input and output parameters β volume, sidetone, and record gain, for
headphone, software and microphone.
Mouse Set the double-tap sensitivity for stylus taps on the touch screen.
MX7II Options Set various device specific configuration options.
Network and Dial Up Options Set network driver properties and network access properties.
Network Capture Start network logging options.
Owner
Set the owner details. Enter notes. Enable / disable Owner display parameters. Enter
Network ID for the device β user name, password, domain.
