XP20 User Manual
3-2
Janam Technologies LLC
You may now go to the main menu and run any application (e.g., note pad). When a barcode is scanned,
its data will be entered wherever the cursor is placed.
Note: The ScanWedge function will be disabled if manual scanning is initiated either by a command API or
by using the Janam Barcode Test program.
Unlock 2D scanning
All of Janam’s mobile computers can be upgraded in the field to read both 1D and 2D barcodes with a
simple firmware upgrade (Part Number 2D-XP-1). With each upgrade, a key code is provided that unlocks
2D scanning capability on the device. To purchase an upgrade for your XP20, contact your reseller or
distributor or Janam customer service.
You will need to provide the product imager ID number so the appropriate five-digit key code sequence
can be assigned. To access the imager ID number, follow these steps:
1.
From the home screen, tap the menu button or date on the
upper left corner of the screen and select info.
2.
The info screen will appear. Press the version button.
3.
Write down the ID number (e.g., 006206A090E-J). When
purchasing the upgrade, provide this 12-digit serial number.
The five-digit key code for enabling 2D scanning on the device
will be sent to you.
After receiving your five-digit key code, follow these steps to enable 2D scanning.
1.
Go to the preferences screen and select settings.
2.
Tap the unlock 2D scan button.
3.
Enter your five-digit key code, and a successful unlock notification will appear.
4.
Select the bar code scanner demo tab at the top of the screen.
5.
Tap the menu button to open symbology config. You can then select enable all to enable every type
of barcode or manually select the barcodes of your choice.
6.
Press OK.
Note: The unlock code will be maintained in the unit’s system after a soft reset, but it will need to be re-
entered after a hard reset. Remember to keep a record of your five-digit key code.
