Membrane Filter Elements
8 Operating Manual Status: 06/2001/01
4 Scope of Delivery
Check the delivery of membrane filter elements immediately upon arrival.
• Check the shipments for damage.
• Check the shipment for completeness. The delivered quantity must agree with the
information on the freight bill.
• Only accept incorrect shipments with written reservation. Document damage and have
it ascertained immediately by the insurance agents.
4.1 Checking and inspecting the membrane filter elements
Check the membrane filter elements and accessories against your purchase order and for
conformity with the geometry of your filter press.
4.2 Membrane filter elements in detail
2
1
3
4
5
6
7
8
9
10
11
1 Centre feed port
(suspension or slurry canal)
2 Stayboss
3 Sealing edge
4 Filtering surface (drainage surface)
5 External connection for squeeze
medium (individual inflation system)
6 2-way spigot
7 3-way spigot
8 Outlet elbow
9 Handles for automatic plate shifting
10 2-screw handle
11 3-screw handle
12 Cloth dog
12
