1. This electric water heater shall be installed in the solid wall. If the strength
of the wall can not bear the load equal to two times of the total weight of the
heater filled fully with water, it is necessary to install a special support.
2. After selecting a proper location, determine the positions of the two install
holes used for expansion bolts with hook (determined according to the
specification of the product you select). Make two holes in the wall with the
corresponding depth by using a chopping bit with the size matching the exp-
ansion bolts attached with the machine, insert the screws, make the hook
upwards, tighten the nuts to fix firmly, and then hang the electric water heater
on it (see Fig.2).
3. Install the supply socket in the wall. The requirements for the socket are as
follows: 250V/10A for 2100W,250V/16A for 3000W, single phase, three
electrodes. It is recommended to place the socket on the right above the
heater. The height of the socket to the ground shall not be less than 1.8m
(see Fig.3).
80 100
297
447
1.8m
