3 Product Specifications
3.1. CS-E9DKEW CU-E9DKE
Unit CS-E9DKEW CU-E9DKE
Cooling Capacity kW
kcal/h
BTU/h
2.6 (0.80 - 3.00)
2,240 (690 - 2,580)
8,870 (2,050 - 10,200)
Heating Capacity kW
kcal/h
BTU/h
3.6 (0.80 - 5.00)
3,100 (690 - 4,300)
12,300 (2,050 - 17,100)
Moisture Removal l/h
Pint/h
1.6
(3.4)
Power Source (Phase, Voltage, Cycle) ø
V
Hz
Single
230
50
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Lo m
3
/min (cfm) Cooling; 6.2 (220) —
Heating; 6.6 (230)
Me m
3
/min (cfm) Cooling; 7.9 (280) —
Heating; 8.6 (300)
Hi m
3
/min (cfm) Cooling; 9.6 (340) Cooling; 29.8 (1,050)
Heating; 10.5 (370)
SHi m
3
/min (cfm) Cooling; 9.9 (350) —
Heating; 10.8 (380)
dB (A) Cooling; High 39, Low 26 Cooling; 46
Heating; High 40, Low 27 Heating; 47
Noise Level
Power level dB Cooling; High 50 Cooling; High 59
Heating; High 51 Heating; High 60
Electrical Data Input W Cooling; 600 (175 - 780)
Heating; 845 (165 - 1,360)
Running Current A Cooling; 2.9
Heating; 4.0
EER W/W (kcal/hw), BTU/hw Cooling; 4.33 (3.73), 14.8
COP W/W (kcal/hw), BTU/hw Heating; 4.26 (3.67), 14.6
Starting Current A 4.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G (gas side) ; 3/8”
L (liquid side) ; 1/4”
G (gas side) ; 3/8”
L (liquid side) ; 1/4”
Drain
Hose
Inner diameter mm 12 —
Length m 0.65 —
7
CS-E9DKEW CU-E9DKE / CS-E12DKEW CU-E12DKE
