17 Replacement Parts List (Outdoor Unit)
17.1. CU-E9DKE CU-E12DKE
REF NO. DESCRIPTION & NAME QTY. CU-E9DKE CU-E12DKE REMARKS
1 CHASSY ASSY 1 CWD50K2073
←
2 ANTI-VIBRATION BUSHING 3 CWH50077
←
3 COMPRESSOR 1 5RS102XBC01
←
O
4 NUT-COMPRESSOR MOUNT 3 CWH56000
←
5 SOUND PROOF MATERIAL 1 CWG302293
←
6 FAN MOTOR BRACKET 1 CWD541030
←
7 FAN MOTOR 1 CWA951418 CWA951309 O
8 SCREW - FAN MOTOR BRACKET 2 CWH551060
←
9 SCREW - FAN MOTOR MOUNT 4 CWH55406
←
10 PROPELLER FAN ASSY 1 CWH03K1006
←
11 NUT - PROPELLER FAN 1 CWH56053
←
12 CONDENSER 1 CWB32C1560 CWB32C1599
13 TUBE ASS’Y CO (CAP./CHK VALVE) 1 CWT01C3257 CWT01C3258
14 HOLDER-COUPLING COMPLETE 1 CWH351023
←
15 3 WAYS VALVE 1 CWB011296 CWB011297 O
16 4 WAYS VALVE 1 CWB001037
←
O
17 SOUND PROOF MATERIAL 1 CWG302292
←
18 2 WAYS VALVE 1 CWB021255
←
O
19 DRYER 1 CWB101017
←
O
20 V-COIL COMPLETE 1 CWA43C2143
←
O
21 REACTOR 1 CWA421050 -
22 SENSOR COMPLETE 1 CWA50C2196
←
23 CONTROL BOARD CASING 1 CWH102273
←
24 TERMINAL BOARD ASSY 1 CWA28K1110
←
25 FUSE HOLDERS 1 K5D203BBA002
←
26 CONTROL BOARD 1 CWH102114
←
27 CONTROL BOARD 1 CWH102115
←
28 ELECTRONIC CONTROLLER 1 CWA73C1672R CWA73C1673R O
29 CONTROL BOARD COVER 1 CWH131104
←
30 SENSOR COMPLETE 1 CWA50C2066
←
31 HOLDER SENSOR 1 CWH321010
←
32 TERMINAL COVER 1 CWH171001
←
33 NUT-TERMINAL COVER 1 CWH7080300
←
34 CABINET SIDE PLATE CO. 1 CWE04C1011
←
35 CABINET SIDE PLATE (LEFT) 1 CWE041031A
←
36 HANDLE 1 CWE161010
←
37 WIRE NET 1 CWD041054A
←
38 CABINET FRONT PLATE CO. 1 CWE06C1039
←
39 CABINET TOP PLATE 1 CWE031014A
←
40 CONTROL BOARD COVER 1 CWH131110
←
41 CONTROL BOARD COVER 1 CWH131093
←
42 OPERATING INSTRUCTION (ENG., ESP., ITA., NED.,
POR., GRE., BUL.)
1 CWF564451
←
43 INSTALLATION INSTRUCTION (ENG., ESP., FRA., DEU.) 1 CWF612674
←
44 L-TUBE 1 CWH5850080
←
45 INSTALLATION INSTRUCTION (NED., GRE., ITA., POR.) 1 CWF612675
←
46 INSTALLATION INSTRUCTION (BUL.) 1 CWF612676
←
47 OPERATING INSTRUCTION (FRA., DEU., SWE., NOR.) 1 CWF564445
←
48 PACKING-L.TUBE 1 CWB81012
←
49 SOUND PROOF BOARD 1 CWH151025
←
(Note)
•
All parts are supplied from PHAAM Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
