1.1 General Features
96 Feature Manual
Programming Manual References
[PT Programming]
[009] Extension Number
[115] Extension Ring Tone Pattern
[128] Ringback Tone Pattern
[604] Extension Name
[PC Programming]
9.1.3 Numbering Plan [1-3]
9.1.11 Detail [1-10]—Extension—Ring Tone Pattern, Extension—Ringback Tone Pattern
9.2.3 PT personal settings [2-3]—Alternate Receiving
Feature Manual References
1.1.61 Flexible Buttons
2.2.1 Tones/Ring Tones
Operating Manual References
1.3.3 Alternate Calling—Ring/Voice
1.3.51 Intercom Call
3.1.2 Personal Feature Assignment—Alternate Receiving—Ring/Voice
3.1.3 Flexible Button Assignment—DSS button
1.1.70 LED Indication
Description
The LED (Light Emitting Diode) of the Message/Ringer Lamp and the following buttons (Line Status Buttons
and Corresponding Extension Status Button) can indicate line status with a variety of light patterns.
Line Status Buttons: Single-CO (S-CO), Group-CO (G-CO), Other-CO (O-CO), INTERCOM
Corresponding Extension Status Button: Direct Station Selection (DSS)
1. Light Pattern of the Message/Ringer Lamp
• Incoming call from an outside (CO) line/another extension: Red flashing
• Message(s) present (no incoming call): Red on
• No messages present and no incoming call: Off
Type Description
Ringback Tone Indicates the call is being received at the called party's extension.
Confirmation Tone Indicates the called party has set voice-calling.
Busy Tone Indicates the called party's extension is busy.
DND Tone Indicates the called party has set Do Not Disturb (DND).
