- 48 -
●
Mode change
– Press and hold for approx. 1 second to change the mode between
3D and 2D (view a 3D image in 2D).
– When power is off, press and hold for approx. 5 seconds to change
to registration mode.
Watching 3D 3D Eyewear - Registration
●
Indicator lamp
– Lights or flashes during use to show the status (see below).
Protection film
– Peel off the protection film on both side of the lens.
Insulating sheet
Battery cover
– When using for the first time, remove the insulating sheet. Pull the
insulating sheet.
– To replace the battery
Watching 3D 3D Eyewear - Replacing battery
■ Indicator lamp status
●
Lights red for 2 seconds when turned on:
Sufficient battery level
●
Flashes 5 times when turned on:
Low battery level
●
Flashes red:
Under registering
●
Flashes red once every 1 second:
Under reconnecting to the TV
●
Flashes red 3 times:
Power off (Press and hold for more than 3 seconds when in use,
or automatically power off when registering / reconnecting fails, or
connection is lost)
●
Flashes red once every 2 seconds when in use:
3D mode is selected.
●
Flashes red twice every 4 seconds when in use:
2D mode is selected.
