13A
29
30
31B
32
31
33
POD ADAPTER INSTALLATION / REMOVAL
To transform the machine for pod operation, proceed as follows:
1. Unscrew
Screw (31B) and remove Filter (30) - see Figure 1.
2. Remove
Adaptor Disc (29) - see Figure 1.
3. Assemble
Filter (32) and fix it with the Screw (31) - see Figure 2.
4. Use the specific
Pod-Filter Holder (33) - see Figure 2.
CLEANING THE MACHINE
Before turning your machine “OFF” do the following:
1. PORTAFILTER / GROUP
a. Back Flushing - Remove used coffee “puck” from
Portafilter (8).
Activate
Pump Switch (5) for approximately 5 seconds using Single Cup
Filter in Portafilter. Repeat 2-3 times. “Puly Caff”* group cleaner may be
used to clean out
Portafilter and Brewing Group (7). See instructions
on package.
b. Wash
Portafilter with hot water from Brewing Group.
2. STEAM JET
a. Turn on steam jet - Make sure the holes at end of
Steam Jet (10) are
free of dried milk solids.
b. Wipe excess milk off of
Steam Jet with damp cloth.
c. Switch Off.
d. For stubborn milk deposits, soak
Steam Jet overnight in pitcher of water.
Remove loosened milk with wet cloth.
3. BOTTOM DRIP PAN
a. Pull out to release tray. Wash with soap and warm water.
4. WATER RESERVOIR
a. Water reservoir may be pulled out for cleaning.
Figure 1.
Ground Coffee Set-UP
Figure 2.
Pod Set-UP
* “Pod-Filter Holder” is available online at
www.pasquini.com.* “Puly Caff” is available online at www.pasquini.com.
