Exploded Parts-VF35 Gas Model
L22-382 Rev 1 (8/14)
12
ITEM # PART # PART DESCRIPTION
1 A1512002-C CABINET SIDE LEFT-HAND
2 A1512004-C CABINET SIDE RIGHT-HAND
3 A1635101-C CABINET BACK SG14,SG14R,SG14T
4 A1635201-C CABINET BACK BOTTOM SG14,SG14R,SG14T
5 A1849601-C CABINET FRONT SPACER SG14,SG14R,SG14T
6 A1235201-C CABINET FRONT BOTTOM BRACE SG14,SG14R,SG14T
7 A1105402-C BASKET HANGER SG14,SG14R,SG14T
8 A3526002-C FLUE REAR HEAT DEFLECTOR SG14
9 A4106902-C SPLASH BACK SG14,SG14R,SG14T
10 B2304101-C DOOR ASSEMBLY SG14,SG14R,SG14T
11 B3630901-C FRONT PANEL TOP DECK WELDMENT SG14,SG14R,SG14T
12 B3632301-C FRONT PANEL ASSEMBLY SG14,SG14R,SG14T
13 B3801801 HINGE WELDMENT LOWER RIGHT HAND SG*
14 B3802401 HINGE WELDMENT UPPER RIGHT HAND SG*
15 A1847002 BRACKET MAGNETIC CATCH
16 60132001 STUD SPLASH BACK SCREW ON
17 P6071300 MAGNETIC CATCH STANDARD
18 PP11006 HANDLE DOOR RECESSED PLASTIC
19 SEE DRAWING G CASTER SWIVEL 9" NON-LOCKING
20 SEE DRAWING G CASTER SWIVEL 9" LOCKING
N/A SEE DRAWING G LEG SET W/HARDWARE 9" (4-PACK)
21 PP10023 SCREW 10-24 X 3/8 SELF TAPPING
22 P0075400 SCREW 10-24 X 1/2 SELF TAPPING
23 P0020600 SCREW 1/4-20 X 5/8 HEX HEAD CAP ZN
24 60125801 SCREW 10-24 X 3/8 TRUSS HEAD SLOTTED LOCKING SST
25 60118201 BOLT 1/4-20 X 3/8 HEX FLANGE HEAD
26 P0093300 NUT HEX (KEP) 10-24 ZN
27
NOT SHOWN
(INCLUDES
ITEMS: 1-6 & 21)
B1822302-C CABINET ASSEMBLY STAND ALONE SG14,SG14R,SG14T
F) Standard Cabinet Drawing
Standard Cabinet Drawing List
