Exploded Parts-VF35 Gas Model
L22-382 Rev 1 (8/14)
14
G) ACCESSORIES
Accessories Drawing Parts
ITEM # PART # PART DESCRIPTION
1 A3301001 CLEAN-OUT ROD
2 PP10056 CLEANING BRUSH NYLON
3 A2510101 DRAIN EXTENSION
4 CONTACT PITCO FRONT WORKSHELF
5 CONTACT PITCO SIDE WORKSEHELVE/DRAINBOARD
6 CONTACT PITCO REAR WORKSHELF
7 CONTACT PITCO REAR WORKSHELF INSERT
8 CONTACT PITCO SPLASH GUARD SIDE
9 60132401 9" LEG
B3900704 9" LEG SET OF 4 WITH HARDWARE
60115301 9" LEG WITH BOTTOM BOLT FLANGE ADJUSTABLE
10 PP10814 9" CASTER NON-LOCKING
B3901504 9" CASTER SET OF 4 (2 LOCKING, 2 NON-LOCKING)
B3902302 9" RIGID CASTER NON-LOCKING
11 PP10815 9" CASTER LOCKING
B3902304 9" RIGID CASTER LOCKING
12 P6072145 TWIN BASKET
P6072146 TWIN BASKET FINE MESH
P6072147 TRIPLE BASKET SG14, SG14R
P6072143 SQUARE BULK BASKET FRONT HANDLE
P6072144 SQUARE BULK BASKET FINE MESH FRONT HANDLE
13 P6073148 TUBE RACK
A4500201 TUBE SCREEN
B7425301-C FISH GRID SG14
14 A1842302-C CABINET BACK
15 B2101518-C TANK COVER ASSEMBLY
16 A3340601-C TANK BACK STANDOFF SG14
