Limitorque MX DeviceNet Field Unit FCD LMENIM2328-00 – 11/05
flowserve.com
4.2.1 DI_Position_and_Bus_Mode_Chan
Table 4.12
Value Definition
0x21 Remote + Opened
0x22 Remote + Closed
0x24 Remote + Opening
0x28 Remote + Closing
0x30 Remote + Stop
0x41 Local + Opened
0x42 Local + Closed
0x44 Local + Opening
0x48 Local + Closing
0x50 Local + Stop
0x81 Stop + Opened
0x82 Stop + Closed
0x84 Stop + Opening
0x88 Stop + Closing
0x90 Stop + Stop
4.2.2 DI_Position_Chan
Table 4.13
Bit 7  Bit 6  Bit 5  Bit 4  Bit 3  Bit 2  Bit 1  Bit 0 
Reserved Reserved Reserved Stop Closing Opening Closed Opened
Table 4.14 – Possible values of DI_Position_Chan
Value Definition
0x01 Opened
0x02 Closed
0x04 Opening
0x08 Closing
0x10 Stop
4.2.3 DI_Actuator_Faults_1_Chan
Table 4.15
Bit 7  Bit 6  Bit 5  Bit 4  Bit 3  Bit 2  Bit 1  Bit 0 
Reserved Reserved Motor Over
Temp
Phase Error Over Torque Manual
Moved
Valve
Jammed
Monitor
Relay
