APPENDIX A
Product Specifications
The following tables summarize the V660’s hardware and firmware features.
Table 20 Hardware Specifications
Dimensions (L x W x D) 108 x 45 x 16.7 mm
Weight 96 g
Power Specification 5.6 V, 0.8 A
Ports USB (10-pin I/O connector)
T-Flash Port
Camera 1.3 megapixel CMOS
Antenna Quad-band GSM internal antenna
2.4GHz WLAN internal antenna
LCD Screen 1.9-inch QCIF
176 x 220 resolution
64,000 colors
Infra-red Connection IrDA (infra-red Data Association) 1.2 SIR (115kbps at 30cm)
Operating Temperature -10 ~ 60 C
Storage Temperature - 40 ~ 80 C
Operating Humidity 10 ~ 90 %
Storage Humidity 5 ~ 95 %
Memory Flash: 64MB
RAM: 64MB
RADIO SPECIFICATIONS
Communications
Standards
IEEE 802.11b
IEEE 802.11g
ETSI GSM 05.05
ETSI GSM 11.10
3GPP 51.010
Frequency IEEE 802.11b/g: Industrial Scientific Medical Band 2.4 ~ 2.4835 GHz
GSM850 / GSM900 / DCS1800 / PCS1900
IEEE 802.1b/g
Operating Channels
North American and Taiwan: 11
Europe: 13
IEEE 802.1b/g Data
Rate
IEEE 802.11b: 11Mbps with automatic fallback to 5.5, 2, 1 Mbps
IEEE 802.11g: 54Mbps with automatic fallback to 48, 36, 24, 18, 12, 9, 6
Mbps
